Welded Wire Fence Alternative to Ornamental & Chain Link

The Prism 3-D Fence System offers you the protection of high-security mesh as part of an attractive security fence solution.

  • Quick and efficient installation
  • Betafence’s exclusive Architectural Grade Powder Coat lasts up to 5 times longer than competitors’ powder coatings
  • 10 year warranty
  • Attractive security fence solution

Specifications

Prism panels have a width of 8.2 feet and heights ranging from 4 to 8 feet. The panels have vertical barbs of 1.2 inches on one side and are reversible (barbs at top or at bottom). Mesh size is 6” x 2” for the beam sections. The heavy wires guarantee strength and rigidity.

Recommended Posts

The panels are attached with high strength steel brackets to the front side of galvanized steel square tubular posts.

Gate Options

Swing, sliding and cantilever gates are available for the Prism 3-D Fence System.

Superior Coating

The Prism 3-D panels are manufactured using galvanized steel wire, coated with Betafence’s exclusive Architectural Grade Powder Coat. This coating is super-durable and environmentally sound. Our powder coating provides the industry’s highest weatherability and Gloss Retention in UV.

Warranty

Prism 3-D is backed by a 10 year Manufacturer’s Warranty.

Prism-3-D

Prism 3D

Prism-3-D

Assortment

Determining the correct type of fence for your application is critical. To secure and protect your investments, see the chart below to guide you in determining the best solution.

Mesh Openings in. Panel Width ft. Wire Gauge Panel Height ft. Number of Bends Brackets per Post
6×2 8.2 6 4 2 3
6×2 8.2 6 5 3 4
6×2 8.2 6 6 4 5
6×2 8.2 6 8 4 7

Building Inspired Fences

We believe that each fence should be a function of need and design so we would like to help you find the right fence.
